Desription:
1, Power:20-320W
2, Working temperature:-40℃/+50℃
3,Protection class: IP66
4, Impact resistance class:IK09
5, Safety class:I,II
6, Power Supply lighting protection:3;6;10KV(optional)
7, Dimming:1-10V;DALI;Midnight dimming
8, Mounting vertical,horizontal: Ø50-60
9, Warranty:5 years
Parameter:
| Item | Model | Wattage | Product Size | House Weight | Installtion Spigot | Led Brand | Driver Brand | CCT | SPD | Protect Class | Warranty |
| 1 | SY-1801C | 80w | 600x300x130mm | N.W.
5.5 kg G.W. 6.5 kg | D50mm D60mm D76mm | Lumileds
3030 96pcs | Philips | 3000K 4000K 5000K 6000K | 10KV+10KA | IP66 IK08 | 5Years |
| 2 | 100w | Lumileds
3030 126pcs | |||||||||
| 3 | 120W | Lumileds
3030 144pcs | |||||||||
| 4 | 150W | Lumileds
3030 168pcs | |||||||||
| 5 | SY-1801B | 150w | 700x360x140mm | N.W.
8.3kg G.W. 9.8kg | D50mm D60mm D76mm | Lumileds
3030 168pcs | Philips | 3000K 4000K 5000K 6000K | 10KV+10KA | IP66 IK08 | 5Years |
| 6 | 200W | Lumileds
3030 224pcs | |||||||||
| 7 | 240W | Lumileds
3030 280pcs | |||||||||
| 8 | SY-1801A | 250w | 800x360x140mm | N.W. 11.2kg G.W. 13kg | D50mm D60mm D76mm | Lumileds
3030 280pcs | Philips | 3000K 4000K 5000K 6000K | 10KV+10KA | IP66 IK08 | 5Years |
| 9 | 300w | Lumileds
3030 336pcs |
